Lưu lượng kế dạng phao, Model EA
Giải đo (min./max.):
Nước: 0.002 / 2.5 L/min
Khí: 0.1 / 90 NL/min at +20°C / 1.013 bar (abs)
Overview
Variable area flow meter Model EA with adjustable flow alarm is designed for applications where continuous flow control is essential. The adjustable flow alarm and clear scale guarantees easy and reliable flow monitoring. Typical applications are heat treatment ovens and automatic welding lines.
Technical Data | ||
Body | Acrylic (PMMA) | |
Valve housing/plugs | Nylon or AISI 316 | |
Valve spindles | AISI 316 | |
Alarm float | AISI 316 | |
Seals | Nitrile (*Viton®, EPDM) | |
Max. pressure | 10 bar | |
Max. temperature | 75°C | |
Connections | BSP 1/4", thread adapters must be used for NPT connections | |
Accuracy | ± 5% F.S. (H2O, +20°C) | |
Alarm sensor | NAMUR or PNP/NPN | |
Weight | 360 g | |
*) Special construction on request |
